You select a combination of any two gauge sets:
- A/D Type gauge set allows the overdrive oil pump to operate while indicating oil pressure since the custom machined steel fitting duplicates the standard operating valve plug, while providing oil pressure connection to the gauge.
- J Type gauge set connects to the overdrive case at the test port.
- LH Type gauge set connects to the overdrive case by replacing the relief valve plug.
Combination Kits Include:
- (Only one) 0 > 600 PSI – 2.5 inch diameter pressure Gauge – liquid (glycerin) filled, which helps absorb vibration and pressure spikes, increasing the service life of the gauge. The dampening action of the liquid also reduces pointer flutter and lubricates the internal parts of the gauge.
- The allowable operating/ambient temperature range for the glycerin is -4F to 140F (-20C to 60C).
- Gauge: 304 stainless steel case, polycarbonate window, black finished galvalume pointer, galvalume dial (white background with blue and black markings), brass movement, phosphor bronze bourdon tube.
- High pressure 3000 psi hose and brass connecting fittings.
